iEPF-10000S (Arrow Lake-S) Series Expandable Edge AIoT Platform

Processor System

CPU	Intel® Core™ Ultra processor (Arrow Lake-S), up to 125W
Chipset	Intel® Q870 or Intel® W880 SKU (Option)
Socket	LGA1851
BIOS	AMI SPI 256 Mbit

Discrete Graphic Card Option

iEPF-10000S Series NVIDIA Graphic Card Option	Support NVIDIA GPU (1~2pcs): RTX PRO 6000 Blackwell Workstation Edition (Build-To-Order), RTX PRO 6000 Blackwell Max-Q Workstation Edition, RTX PRO 5000 72GB Blackwell, RTX PRO 5000 Blackwell, RTX PRO 4500 Blackwell Workstation Edition, RTX PRO 4000 Blackwell, RTX PRO 4000 Blackwell SFF Edition, or RTX PRO 2000 Blackwell
iEPF-10000S Series Intel Graphic Card Option	Support Intel GPU (1~2pcs): Intel Arc™ Pro B70, Intel Arc™ Pro B65, Intel Arc™ Pro B60, Intel Arc™ Pro B50, Intel Arc™ A770, or Intel Arc™ B580
iEPF-10000S Series AMD Graphic Card Option	Support AMD GPU (1~2pcs): AMD Radeon™ AI PRO R9700

CPU Graphics

Controller	Intel® Xe LPG Graphics
HDMI	HDMI 2.1 TMDS Max resolution up to 7680x4320@60Hz
DisplayPort	DisplayPort 1.4a, DP++ Max resolution up to 4096x2160@60Hz
MultiDisplay	Quad display (Included 2 output from Type-C)

MB Expansion Slot

PCIe	2 x PCIe Gen5 Slots (PCIE1/PCIE5: single at x16 (PCIE1); dual at x8 (PCIE1) / x8 (PCIE5)) 2 x PCIe x4 (Gen4) for Q870 SKU or 3 x PCIe x4 (Gen4) for W880 SKU 2 x PCIe x1 (Gen4)
M.2	1 x M.2 (Key E, 2230) with PCIe Gen4 x1, USB 2.0 and CNVi for Wireless 1 x M.2 (Key B, 3042/3052) with PCIe Gen4 x1 , USB 2.0

MB Rear I/O

HDMI	2 x HDMI 2.1 TMDS
DisplayPort	1 x DP 1.4a++
Ethernet	2 x 1 Gigabit LAN 1 x 10 Gigabit LAN (Option for W880 SKU)
USB	5 x USB 3.2 Gen2 1 x USB4/Thunderbolt™4 (5V/3A, supports DP 2.1 display output) * For Thunderbolt support, please refer to support list.
Audio	3 (Mic-in, Line-in, Line-out)
COM	COM1, COM2 (RS-232/422/485)

MB Internal Connector

USB	2 x USB 3.2 Gen1 (Chasis front side) 1 x USB 3.2 Gen2 vertical Con 2 x USB 2.0 (1 x USB2 header) 1 x USB4/Thunderbolt™4 (5V/3A, supports DP 2.1 display output) * For Thunderbolt support, please refer to support list
COM	COM3 (RS-232/TTL 5V/ccTalk, switch by Jumper setting) COM4, COM5, COM6 (RS-232)
Parallel	1 (shared with GPIO)
GPIO	8 x GPI, 8 x GPO (shared with LPT header)

Memory

Technology	Dual Channel ECC/non-ECC DDR5 6400/5600 MHz * 1DPC 6400MHz (Ultra 9/7/5K), 5600MHz (Ultra 5 non-K) / 2DPC 1R 5600MHz / 2DPC 2R 4400MHz * Only CU-DIMM can support up to 6400MHz * ECC feature only supported by W880
Capacity	256GB (64GB per DIMM)
Socket	4 x 288-pin Long-DIMM

Audio

Interface	Realtek ALC897, High Definition Audio. Line-in, Line-out, Mic-in (Rear Side)

Ethernet

Controller/ Speed	LAN1: Intel® I219LM with 10/100/1000 Mbps, supports vPro LAN2: Intel® I210AT with 10/100/1000 Mbps LAN3: Marvell AQC113 with 10/100/1000/2500/5000/10000 Mbps (Option for W880 SKU)
Connector	2 or 3 x RJ-45

Security

TPM	TPM 2.0 onboard IC

Storage

M.2	1 x M.2 (Key M, 2242/2280/22110/25110) with PCIe Gen5 x4 for SSD 1 x M.2 (Key M, 2242/2280) with PCIe Gen4 x4 for SSD
SATA	2.5"/3.5" HDD bays x 4
RAID	Intel® VMD RAID 0/1/5/10 **supported by identical interface (PCIE or SATA) PCIE interface: 2 x M.2 Key M SATA interface: SATA port

Power Requirements

Power Supply Unit	1000W: Rated Output Power Input Voltage 100-240V 1600W: Rated Output Power 1600W at 115-240V, Rated Output Power 1300W at 100-240V
Power On	AT/ATX Supporte - AT : Directly PWR on as power input ready - ATX : Press button to PWR on after power input ready

Mechanical

Dimensions	597mm (D) x 206mm (W) x 455.1mm (H)

The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.

Ordering Information

Model Name	Part Number	Description
Model Name	IEPF-10000S-FS16/AI	Part Number	90PXGEB0-10430600	Description	Intel® Core™ Ultra 9 Processor 285 IMB-X1715-10G NON-Wide Temperature DDR5 UDIMM 48GB 288P x2 NON-Wide Temperature M.2 2280 M Key PCIE Gen4x4 SSD 1TB 850W PSU, US Power Cord Intel Arc Pro B60 24GB GDDR6 x2
