EOL
SOM-QA101 QSeven Motherboard
- AMD Embedded G-Series SOC processor
- Supports DDR3L 1333, up to 8GB
- 1 x HDMI , 1 x DP , 1 x LVDS (By Carrier Board)
- 1 x USB 3.0, 5 x USB2.0 , 2 x SATA3 (By Carrier Board)
- 3 x PCIe x1 slot (By Carrier Board)
- 1 x Mini-PCIe (By Carrier Board)
- 1 x mSATA (By Carrier Board)
- 2 x Intel LAN (By Carrier Board)
- 12~24V DC-in (By Carrier Board)
Specification
Processor System
| CPU | GX-412HC, QC, 1.2GHz, 7W |
|---|---|
| Chipset | By CPU |
Form Factor
| Dimensions | Qseven (2.8-in x 2.8-in, 7.1 cm x 7.1 cm) |
|---|
Memory
| Technology | DDR3L 1333MHz |
|---|---|
| Capacity | 8 GB |
Graphics
| Controller | Integraded AMD Radeon™ R3E Graphics |
|---|---|
| LVDS | Supports max resolution up to 1920 x 1200@60Hz |
| HDMI | Supports max resolution up to 4096 x 2160@24Hz |
| DisplayPort | Supports max resolution up to 4096 x 2160@60Hz |
| MultiDisplay | Dual Display |
Expansion Slot
| PCIe | 3 x PCIex1 (By Carrier Board) |
|---|---|
| mini-PCIe | 1 x full/ half size (By Carrier Board) |
| mini-PCIe/mSATA | 1 x full size (By Carrier Board) |
Ethernet
| Controller/ Speed | 10/100/1000 Mbps |
|---|---|
| Connector | 1 x Intel® I211 (By Carrier Board) |
Rear I/O
| HDMI | 1 (By Carrier Board) |
|---|---|
| DisplayPort | 1 (By Carrier Board) |
| Ethernet | 1 (By Carrier Board) |
| USB | 1 x USB3.0 , 5 x USB2.0 (By Carrier Board) |
| Audio | 2 (By Carrier Board) |
| Serial Port | 2 x RS-232 (By Carrier Board) |
| PS2 | 1 (By Carrier Board) |
Internal Connector
| LVDS | 1 (By Carrier Board) |
|---|---|
| GPIO | 4 x GPI + 4 x GPO (By Carrier Board) |
| SATA PWR Output | 1 (By Carrier Board) |
Storage
| SATA | 2 x SATA3 (By Carrier Board) |
|---|
Watchdog Timer
| Output | From Super I/O to drag RESETCON# |
|---|---|
| Interval | 256 Segments, 0, 1, 2, ...255sec |
Power Requirements
| Input PWR | By Carrier Board |
|---|---|
| Power On | By Carrier Board |
Environment
| Operating Temp | 0ºC ~ 60ºC |
|---|---|
| Storage Temp | -40° C – 85° C |
| Operating Humidity | 5% ~ 90% |
| Storage Humidity | 5% ~ 90% |
The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
