M2B-LAN-2P R2 kit
- M.2 Key B-M 3052 to dual LAN
- Intel® I210AT Gigabit Ethernet Controllers
- Compliant with IEEE 802.3u Auto-Negotiation
- Supports 10/100/1000 Mbps transfer rates
產品規格
Specifications
| Form Factor | Main Board: M.2 key B-M 3052 Daughter Board: Customized |
|---|---|
| Function | M.2 Key B-M to dual 1G LAN |
| Dimensions (W x L x H/mm) | Main Board: 30 x 52 x 7.9 Daughter Board: 80 x 25.5 x 19 |
| Controller / Major IC | - ASMedia ASM1182e - Intel® I210AT |
| Input Interface/Power | PCI Express x1 |
| Output Interface/Power | 2 x 1G LAN |
| Output connector | 2 x 1G RJ45 Ports |
| Operating Temperature | -20ºC ~ 70ºC |
| Storage Temperature | -40ºC ~ 85ºC |
| Package | 1 x LAN Cable 1 x Screw (M2*2) |
規格更改時恕不預先通知。品牌和產品名稱歸各自公司所有。不保證任何配置與產品實物規格相同。
