AI BOX-A395 AI Max 300 Box Series
- AMD Ryzen™ AI Max 300 Series (Strix Halo)
- Supports 128GB Onboard LPDDR5X-8000 memory
- 2 x USB4, 1 x USB 3.2 Gen2 Type C, 2 x USB 3.2 Gen2, 2 x USB 2.0
- 1 x M.2 Key E (WiFi7 Module)+2 x M.2 Key M
- 1 x Realtek 2.5 Gigabit LAN, 1 x Marvell 10 Gigabit LAN
- Supports Quad display, 2 x HDMI 2.1, 3 x DP 2.1 (2 from USB4, 1 from Type-C)
- 1 x Mic-in, 1 x Line-out
- TPM 2.0 onboard IC
- Support Redundant BIOS
- Supports RAID 0/1
- Supports both Windows 11 and Linux OS
- 200 x 100 x 232mm (7.87" x 3.94" x 9.13"), Fanned Barebone
產品特色
產品規格
Processor System
| CPU | AMD Ryzen™ AI Max 300 Series (AMD Ryzen™ AI Max+395, 16C, Boost up to 5.1GHz) |
|---|---|
| BIOS | 2 x AMI SPI 256 Mbit* *This motherboard has two BIOS chips, a primary BIOS (BIOS1) and a redundant BIOS (BIOS2), which enhances the safety and stability of your system. Normally, the system will work on the primary BIOS (BIOS1). However, if the primary BIOS is corrupted or damaged, the system will recover from redundant BIOS (BIOS2) to primary BIOS BIOS1). When the system fails to recover, the redundant BIOS (BIOS2) will take over on the next system boot with warning message. For safety issues, users are not able to update the redundant BIOS (BIOS2) manually. |
Memory
| Technology | Onboard LPDDR5X, up to 8000 MT/s |
|---|---|
| Capacity | 128GB |
Graphics
| Controller | AMD Radeon™ 8060S Graphics |
|---|---|
| HDMI | HDMI 2.1 Max resolution up to 7680x4320@60Hz |
| DisplayPort | DisplayPort 2.1 Max resolution up to 7680x4320@60Hz |
| MultiDisplay | Quad display (included 3 outputs from Type-C) |
Expansion Slot
| M.2/WLAN | 1 x Wi-Fi 7 802.11be+ BT 5.4 |
|---|
Audio
| Interface | Realtek ALC897, High Definition Audio |
|---|
Ethernet
| Controller/ Speed | LAN1: Marvell AQC113 with 10/100/1000/2500/5000/10000 Mbps LAN2: Realtek RTL8125BG with 10/100/1000/2500 Mbps |
|---|---|
| Connector | 2 x RJ-45 |
Rear I/O
| HDMI | 2 x HDMI 2.1 |
|---|---|
| Ethernet | 1 x 10 Gigabit LAN 1 x 2.5 Gigabit LAN |
| USB | 2 x USB4 (5V/3A, supports DP 2.1 output) 1 x USB 3.2 Gen2 (Type C ,5V/3A, supports DP 2.1 output) 2 x USB 3.2 Gen2 |
| Audio | 2 (Mic-In/Line-Out) |
Top I/O
| USB | 2 x USB2.0 |
|---|
Storage
| M.2 | 1 x M.2 (Key M, 2242/2280) with PCIe Gen4 x4 for SSD 1 x M.2 (Key M, 2280) with PCIe Gen4 x4 for SSD |
|---|---|
| RAID | Supports RAID 0/1 |
Watchdog Timer
| Output | From Super I/O to drag RESETCON# |
|---|---|
| Interval | 256 Segments, 0, 1, 2, ...255sec |
Power Requirements
| Input PWR | AC INPUT (100-240V, 60-50Hz, 400W) |
|---|---|
| Power On | AT/ATX Supported - AT : Directly PWR on as po wer input ready - ATX : Press button to PWR on after po wer input ready |
Environment
| Operating Temp | 0ºC ~ 40ºC |
|---|---|
| Storage Temp | -40° C ~85° C |
| Operating Humidity | 5% ~ 90% (non-condensing) |
| Storage Humidity | 5% ~ 90% (non-condensing) |
Mechanical
| Construction | Aluminum housing |
|---|---|
| Dimensions (L x W x H) | 200 x 100 x 232mm (7.87" x 3.94" x 9.13") |
| Weight | Net Weight: 2.8KG |
Others
| OS Support | Windows 11 |
|---|---|
| TPM | TPM 2.0 onboard IC |
| Certifications | CE, FCC |
| Packing List | 1 x Power cord, 1 x Handle Kit, 2 x Antenna, 1 x M.2 NUT, 1 x QIG 1 x M.2 Heatsink Module, 1 x M.2 Thermal Pad, 2 x M.2 Screw |
規格更改時恕不預先通知。品牌和產品名稱歸各自公司所有。不保證任何配置與產品實物規格相同。
支援下載
作業系統:
| 說明 | 資訊 | 作業系統 | 日期 | 下載 | |||||
|---|---|---|---|---|---|---|---|---|---|
| 說明 | WIFI_Driver_MediaTek(5.5.0.3498) | 資訊 | Version: 5.5.0.3498 |
作業系統 | Win 11 x 64 | Date | 2026-04-10 | 下載 | |
| 說明 | Bluetooth_Driver_MediaTek(1.1042.0.498) | 資訊 | Size: 10Mib |
作業系統 | Win 11 x 64 | Date | 2026-04-10 | 下載 | |
| 說明 | Realtek_Lan_driver_ver(10074_02052025) | 資訊 | Size: 4894Kib |
作業系統 | Win 11 x 64 | Date | 2026-04-10 | 下載 | |
| 說明 | HD Audio Driver(9929.1) | 資訊 | Size: 56Mib |
作業系統 | Win 11 x 64 | Date | 2026-04-10 | 下載 | |
| 說明 | RAIDXpert2_Windows_GUI(9.3.3.245.53) | 資訊 | Size: 105Mib |
作業系統 | Win 11 x 64 | Date | 2026-04-10 | 下載 | |
| 說明 | RAIDXpert2_Windows_Driver(9.3.3.00245) | 資訊 | Size: 5554Kib |
作業系統 | Win 11 x 64 | Date | 2026-04-10 | 下載 | |
| 說明 | VGA Driver(25.8.1) | 資訊 | Size: 912Mib |
作業系統 | Win 11 x 64 | Date | 2026-04-10 | 下載 | |
| 說明 | Chipset_Driver(7.06.02.123) | 資訊 | Size: 73Mib |
作業系統 | Win 11 x 64 | Date | 2026-04-10 | 下載 | |
| 說明 | 10G LAN Driver(3.1.7.0) | 資訊 | Size: 2731Kib |
作業系統 | Win 11 x 64 | Date | 2026-04-10 | 下載 | |
| 說明 | Nuvoton HighSpeed Setup_v1.8.24.0805 | 資訊 | Size: 7158Kib |
作業系統 | Win 11 x 64 | Date | 2026-04-07 | 下載 |
| 版本 | 更新方式 / 如何更新 | 說明 | 資訊 | 日期 | 下載 | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 版本 | 1.00 | 更新方式 / 如何更新 | BIOS | 說明 | First release | 資訊 | Size: 10 MiB SHA1: d2397b6c4eacd9a51aa7eb67eabdbeb18a0f4254 |
日期 | 2026-04-17 | 下載 | |
| 版本 | 1.00 | 更新方式 / 如何更新 | Windows | 說明 | First release | 資訊 | Size: 10 MiB SHA1: 7d9fd4e2fafd01409bfcf81e6052d9a1af583d1f |
日期 | 2026-04-17 | 下載 |
檔案格式為 PDF，如果您沒有安裝 Adobe Acrobat Reader，請至 Adobe下載。
| 說明 | 語言 | 日期 | 下載 | ||||
|---|---|---|---|---|---|---|---|
| 說明 | User Manual | 語言 | English | 日期 | 2026-04-22 | 下載 | |
| 說明 | Quick Installation Guide | 語言 | English | 日期 | 2026-04-22 | 下載 |
| 說明 | 日期 | 下載 | |||
|---|---|---|---|---|---|
| 下載 | Type C Device Support List | 日期 | 2026-04-08 | 下載 |
