VGA-PWR600W
- [ASRock Industrial Exclusive]
- Supports the following Motherboard:
- IMB-1239-WV, IMB-1240-WV, IMB-X1240-WV
- IMB-1244-WV, IMB-X1244-WV
- IMB-1245-WV Series: IMB-1245P-WV, IMB-1245M-WV
- IMB-A8000 Series: IMB-A8000P, IMB-A8000S, IMB-A8000M, IMB-A8000V
产品规格
Specifications
| Form Factor | Customized |
|---|---|
| Function | 8-pin DC_IN Power to output power boost up to 600W |
| Dimensions (W x L x H/mm) | 90 x 90 x 13 |
| Controller / Major IC | Power controller: TI LM5176PWPR FAN Speed controller: MP1475DJ-LF-Z |
| Input Interface/Power | 1 x 8-pin DC_IN Power connector (+12V~36V) 1 x PS_ON# Header |
| Output connector | 2 x 8-pin VGA Power connector 1 x 4-pin FAN connector |
| VGA Power Output | VGA Loading <350W (with DC-IN +12V~+36V); VGA TDP<350W VGA Loading <600W (with DC-IN +24V~+36V); VGA TDP<600W |
| Operating Temperature | -20 ºC ~ 70 ºC |
| Storage Temperature | -40 ºC ~ 85 ºC |
| Package | 2 x 8-pin to Graphics card cable 1 x PS_ON# cable 1 x PWR 8P to 8P cable |
规格更改时恕不预先通知。品牌和产品名称归各自公司所有。不保证任何配置与产品实物规格相同。
